High speed round sheath cable inner and outer double layer stripping machine WPM-YHT3
High speed round sheath cable inner and outer double layer stripping machine WPM-YHT3
  • High speed round sheath cable inner and outer double layer stripping machine WPM-YHT3

  • Model No: WPM-YHT3
  • Weight: 38KG
    Electrical connection: 110V/220V 50HZ/60HZ
    Power: 300W
    Operation interface: 4.3 inch Chinese and English switching touch screen displayMachine dimension: 450*420*335mm
    Wire cross section:  2-7mm (Round sheath wire)
    umber of wire cores that can be processed: 2 cores, 3 cores, 4 cores
    Air pressure: 0.8Mpa
    Max conduit inside diameter: C 9mm
    Leneth accuracy:+ 0.2mm
    Wire length range: Max 9999mm
    Outer wire strip length; Front end:1-150: rear end:1-150mm
    Blade material: high-speed steel
    Iransport speed:(L=200MM piece/hour) 2000-3000 pieces
    Driving mode: four-wheel drive (silent hybrid stepper motor, 0.lmm forward per step)
  • Inquiry now
Detailed description

High speed round sheath cable inner and outer double layer stripping machine WPM-YHT3
With forward and reverse straightener)(Disconnection device and protective
cover are optional
Weight: 38KG
Electrical connection: 110V/220V 50HZ/60HZ
Power: 300W
Operation interface: 4.3 inch Chinese and English switching touch screen displayMachine dimension: 450*420*335mm
Wire cross section:  2-7mm (Round sheath wire)
umber of wire cores that can be processed: 2 cores, 3 cores, 4 cores
Air pressure: 0.8Mpa
Max conduit inside diameter: C 9mm
Leneth accuracy:+ 0.2mm
Wire length range: Max 9999mm
Outer wire strip length; Front end:1-150: rear end:1-150mm
Blade material: high-speed steel
Iransport speed:(L=200MM piece/hour) 2000-3000 pieces
Driving mode: four-wheel drive (silent hybrid stepper motor, 0.lmm forward per step)

Wire Range 2-7mm YHT3 Wire Stripping Peeling Cutting Machine High Speed Round Sheath Double Layer Peeling Tool


P.S: The wire collecting board and protect cover is not include. if you need add. please contact seller.

Model:WPM-YHT3(High speed round sheath inner and outer double layer peeling machine)
(With disconnection device)(With Forward and reverse straightener)( Protective cover is optional)
Weight:38KG Power:300W
Electrical connection: 110V/220V 50HZ/60HZ
Operation interface: 4.3 inch Chinese and English switching touch screen display
Machine dimension: 450*420*335mm
Wire cross section: ¢2-7mm (Round sheath wire)
Number of wire cores that can be processed: 2 cores, 3 cores, 4 cores
Air pressure: 0.8Mpa Length accuracy: ± 0.2mm
Max conduit inside diameter:¢9mm
Wire length range:Max 9999mm
Outer wire strip length:Front end:1-150; rear end:1-150mm
Blade material: high-speed steel
Transport speed: (L=200MM piece/hour) 2000-3000 pieces
Driving mode: four-wheel drive (silent hybrid stepper motor, 0.1mm forward per step)
